ABB ACS800-04N-12A6-4 Industrial Drive | Single Drive Module 12.6A

ABB ACS800-04N-12A6-4 industrial drive single drive module, rated output current 12.6A, input 380/400/415V three-phase, DTC direct torque control, conformal coated PCBs (N option) for harsh environments, R2 frame, IP20 protection, standard Modbus communication, for motor speed control and process control. Order available.

online consultation

Product Details

1. Product Overview

The ABB ACS800-04N-12A6-4 is a Single Drive Module from ABB's classic ACS800 series industrial drives, specifically designed for cabinet integration installation, with rated output current 12.6A, input voltage 380/400/415V three-phase AC, corresponding to typical motor power of approximately 5.5kW (light-overload) / 4kW (heavy-duty), frame size R2.

The "N" in the model number represents the Conformal Coated PCBs option, meaning the drive's internal printed circuit boards are coated with conformal coating (protective lacquer), providing additional protection in harsh industrial environments with high humidity, corrosive gases, and dust, significantly improving operational reliability and service life under harsh conditions, especially suitable for industries such as petrochemical, chemical, metallurgy, mining, water treatment, and paper.

The ACS800 series uses ABB's patented DTC (Direct Torque Control) technology, achieving high-precision control of motor torque and speed without a motor encoder. DTC technology directly controls the IGBT switching status by real-time calculating motor flux and torque, featuring fast response, high torque control accuracy, excellent low-speed performance, and high starting torque. It can drive various motor types including asynchronous motors, synchronous motors, and servo motors, suitable for almost all industrial motor speed control applications.

The ACS800-04 single drive module adopts a modular design, integrating all necessary components internally including rectifier unit, DC bus, inverter unit, control board (RMIO), I/O terminals, and communication interface. Users only need to install it in the control cabinet, connect input power, output motor, and control signals to put it into operation. The module has a compact structure, and the R2 frame size is small, facilitating flexible layout and multiple side-by-side installations in the control cabinet, maximizing cabinet space utilization.

This drive is equipped with standard Modbus RTU fieldbus communication and supports various optional communication protocols including Profibus DP, DeviceNet, CANopen, Ethernet/IP, Profinet, Modbus TCP, etc., enabling easy integration with various PLCs, DCS, and industrial automation systems for remote monitoring, parameter setting, fault diagnosis, and data acquisition. It is equipped with rich I/O interfaces including digital inputs, digital outputs, analog inputs, and analog outputs, meeting signal connection requirements for most applications, and can be further expanded through optional I/O extension modules.

The ACS800 series has built-in rich Application Macros including Standard macro, ABB Standard macro, Hand/Auto macro, PID Control macro, Torque Control macro, Sequencer macro, etc. Users can quickly select the corresponding application macro according to the application scenario, simplifying parameter setting and commissioning. The built-in PID controller can directly implement closed-loop control of process variables such as pressure, flow, and temperature without an additional PID controller, simplifying system configuration.

For safety functions, the ACS800 supports various optional safety functions including Prevention of Unexpected Start-up (+Q950), Safe Torque Off STO (+Q967), etc., meeting EU Machinery Directive and functional safety standard requirements. Small power models are equipped with standard braking choppers, which, together with external braking resistors, can achieve fast braking and energy consumption, suitable for applications requiring fast stopping or potential energy loads.

The ACS800 series is one of ABB's most successful industrial drive platforms in history, with a huge global installed base, widely used in petrochemical, natural gas, power, metallurgy, mining, cement, paper, water treatment, marine, hoisting, HVAC, and almost all industrial sectors. Although the ACS800 series has been gradually succeeded by the new generation ACS880 series, a large number of ACS800 drives are still in operation worldwide, and spare parts and new demand continue to exist.

Note: This product is an ABB ACS800 series industrial drive single drive module. Specific configuration (I/O count, communication protocol, safety functions, braking unit, etc.) may vary depending on option codes. Some parameters are marked "Contact via email for confirmation." Installation, commissioning, and maintenance should be performed by professional engineers trained in ABB drives.

2. Specifications

表格

Parameter	Value
Brand	ABB (ABB Group, Switzerland)
Model	ACS800-04N-12A6-4
Product Type	Industrial Drive Single Drive Module
Series	ACS800
Mounting Type	Cabinet-installation module (IP20)
Rated Output Current	12.6 A
Typical Motor Power (Light-overload)	5.5 kW (reference, subject to application)
Typical Motor Power (Heavy-duty)	4 kW (reference, subject to application)
Input Voltage	380 / 400 / 415 V AC, 3-phase, ±10%
Input Frequency	48 ~ 63 Hz
Output Voltage	0 ~ input voltage (3-phase sinusoidal PWM)
Output Frequency	0 ~ 300 Hz (typical, Contact via email)
Control Technology	DTC (Direct Torque Control)
Frame Size	R2
Protection Degree	IP20 (standard)
Conformal Coated Option	Yes (N option, Conformal Coated PCBs)
Operating Temperature	-15 ~ +40°C (no derating); +40 ~ +50°C derating (1%/°C)
Storage Temperature	-40 ~ +70°C
Relative Humidity	5 ~ 95% RH, no condensation (Contact via email)
Altitude	≤1000m no derating; >1000m derating (Contact via email)
Braking Chopper	Standard (small power), external braking resistor
Digital Inputs	6 standard (Contact via email, expandable)
Digital Outputs	3 standard (Contact via email, expandable)
Analog Inputs	2 standard (Contact via email, expandable)
Analog Outputs	2 standard (Contact via email, expandable)
Standard Communication	Modbus RTU
Optional Communication	Profibus DP, DeviceNet, CANopen, Ethernet/IP, Profinet, Modbus TCP etc.
Optional Safety Functions	Prevention of Unexpected Start-up (+Q950), Safe Torque Off STO (+Q967)
Application Macros	Standard, PID Control, Torque Control, Sequencer etc.
Built-in PID	Yes (1 set, Contact via email)
Cooling Method	Air cooling
Noise Level	Contact via email (reference ≤62 dB(A))
Weight	Contact via email (R2 frame reference approx. 8-10kg)
Dimensions (H×W×D)	Contact via email (R2 frame reference approx. 370×165×193mm)
Certifications	CE, UL, cUL, RoHS (Contact via email, subject to actual config)
Origin	Contact via email for confirmation (ABB global manufacturing)
HS Code	Contact via email for confirmation (reference 85044090)
Stock Status	Order available
Warranty	12 months

3. Key Features

ABB Classic ACS800 Platform, DTC Direct Torque Control — The ACS800 is ABB's classic high-performance industrial drive platform, using patented DTC (Direct Torque Control) technology, achieving high-precision motor torque and speed control without an encoder, with fast response, high torque control accuracy, excellent low-speed performance, and high starting torque. It can drive various motor types including asynchronous, synchronous, and servo motors, suitable for almost all industrial motor speed control applications.
Conformal Coated PCBs (N Option), for Harsh Industrial Environments — The "N" in the model represents the Conformal Coated PCBs option. The drive's internal PCBs are coated with protective conformal coating, providing additional protection in high humidity, corrosive gas, and dust harsh industrial environments, significantly improving operational reliability and service life, especially suitable for petrochemical, chemical, metallurgy, mining, water treatment, paper industries with harsh environmental conditions.
Single Drive Module Design, Flexible Cabinet Integration — The ACS800-04 is a single drive module form with IP20 protection, specifically designed for cabinet integration installation. It integrates all necessary components including rectifier, DC bus, inverter, control, I/O, and communication internally, with compact structure and small R2 frame size, facilitating flexible layout and multiple side-by-side installations in the control cabinet, maximizing cabinet space utilization, suitable for system integrators and OEM customers customizing control cabinets.
12.6A Rated Output, Covering 5.5kW/4kW Power Range — Rated output current 12.6A, input 380/400/415V three-phase, corresponding to typical motor power of approximately 5.5kW (light-overload) / 4kW (heavy-duty), covering common motor speed control needs in the small-to-medium power range, suitable for various load types including fans, pumps, conveyors, mixers, compressors, and hoists.
Rich Communication Protocols, Seamless Automation Integration — Standard Modbus RTU fieldbus communication, supporting various optional communication protocols including Profibus DP, DeviceNet, CANopen, Ethernet/IP, Profinet, Modbus TCP, etc., enabling easy integration with Siemens, Rockwell, Schneider and other brand PLCs and various DCS systems for remote monitoring, parameter setting, fault diagnosis, and data acquisition, meeting communication needs of different industrial automation systems.
Rich I/O and Application Macros, Fast Commissioning Simplified Configuration — Standard digital inputs/outputs, analog inputs/outputs, meeting signal connection needs for most applications, supporting I/O extension modules. Built-in multiple application macros (Standard, PID Control, Torque Control, Sequencer, etc.), users can quickly select according to application scenarios, simplifying parameter setting and commissioning. Built-in PID controller can directly implement closed-loop control of pressure, flow, temperature and other process variables without an additional PID controller.
Comprehensive Protection Functions, Ensuring Safe Equipment Operation — Built-in comprehensive protection functions including overcurrent, overvoltage, undervoltage, overtemperature, ground fault, motor overload, and short circuit protection, real-time monitoring drive and motor operating status, fast response and equipment protection under abnormal conditions, reducing failure losses. Supports fault recording and historical data storage for fault diagnosis and maintenance analysis.
Optional Safety Functions, Meeting Functional Safety Standards — Supports various optional safety functions including Prevention of Unexpected Start-up (+Q950), Safe Torque Off STO (+Q967), etc., meeting EU Machinery Directive (2006/42/EC) and functional safety standards (IEC 61508 / EN ISO 13849) requirements, suitable for applications with strict personnel safety requirements such as machinery manufacturing, hoisting, conveying, and textile industries.
Standard Braking Chopper, Fast Braking Capability — Small power models are equipped with standard braking choppers, which, together with external braking resistors, can achieve fast braking and energy consumption, suitable for applications requiring fast stopping or potential energy loads (such as hoists, elevators, centrifuges), with fast braking response and short deceleration time, improving production efficiency and equipment safety.
Wide Global Applications, Mature Spare Parts System — The ACS800 series has a huge global installed base, widely used in petrochemical, natural gas, power, metallurgy, mining, cement, paper, water treatment, marine, hoisting, HVAC, and almost all industrial sectors. After years of market verification, the product is mature and reliable, with a complete spare parts supply system and rich technical support resources, making it a classic choice for industrial motor speed control.

5. Model Explanation

Product Model: ACS800-04N-12A6-4

Product Description: ABB ACS800 series industrial drive single drive module, rated output current 12.6A, input 380/400/415V three-phase, DTC direct torque control, conformal coated PCBs option (N), R2 frame, IP20 protection, for motor speed control and process control

Model Breakdown:

表格

Component	Meaning
ACS800	ABB industrial drive series name (Advanced Control System 800)
04	Product form: Single Drive Module, cabinet installation, IP20 protection
N	Option code: Conformal Coated PCBs, for harsh environments
12A6	Rated output current: 12.6 A
4	Voltage class: 380 / 400 / 415 V AC, three-phase

ACS800-04 Product Form Explanation:

04 = Single Drive Module, specifically designed for cabinet integration installation
Distinguished from 01 (wall-mounted), 02 (floor-standing), 07 (cabinet-built) and other mounting forms
Standard protection degree IP20, must be installed in a control cabinet
Power range 0.55~1900kW (full series), this model 12.6A belongs to small-to-medium power range

N Option (Conformal Coated PCBs) Explanation:

Full name: Conformal Coated Printed Circuit Boards
Drive internal PCBs coated with conformal coating (acrylic, polyurethane, or silicone)
Function: Moisture-proof, mold-proof, salt-spray-proof, dust-proof, corrosive gas-proof, improving reliability in harsh environments
Applicable industries: Petrochemical, chemical, metallurgy, mining, water treatment, paper, offshore platforms, etc.
Note: Conformal coated option does not change electrical performance, only improves environmental adaptability

12A6 Current and Power Correspondence Explanation:

Rated output current: 12.6 A
Light-overload application: typical motor power approx. 5.5kW
- Allows 110% overload for 1 minute, or periodic overload
- Suitable for variable torque loads such as fans and pumps
Heavy-duty application: typical motor power approx. 4kW
- Allows 150% overload for 1 minute (once every 5 minutes)
- Suitable for constant torque/heavy-duty loads such as conveyors, mixers, hoists
Specific power matching needs to be confirmed based on motor rated current, load characteristics, and overload requirements

Voltage Class 4 Explanation:

4 = 380 / 400 / 415 V AC, three-phase, ±10%
Input frequency: 48~63Hz
Suitable for most industrial grid voltage standards worldwide
Distinguished from 2 (208~240V), 3 (380~415V), 5 (380~500V), 7 (525~690V) and other voltage classes
Note: This model voltage class code is 4, corresponding to 380/400/415V, cannot be used for other voltage classes

R2 Frame Size Explanation:

R2 = Frame size number 2, one of the smallest frame sizes in the ACS800 series
Suitable for small power range drives
Compact structure, convenient for cabinet integration
Specific dimensions and weight: Contact via email for confirmation (reference approx. 370×165×193mm, 8-10kg)

ACS800 Series Common Model Comparison Reference:

表格

Model	Rated Current	Typical Power (Light/Heavy)	Frame
ACS800-04-0004-4	4A	1.5kW / 1.1kW	R2
ACS800-04-0005-4	5.4A	2.2kW / 1.5kW	R2
ACS800-04-0009-4	9.4A	4kW / 3kW	R2
ACS800-04N-12A6-4	12.6A	5.5kW / 4kW	R2
ACS800-04-0016-4	16A	7.5kW / 5.5kW	R3

Note: The above comparison data comes from ABB public catalog, for reference only, specific subject to official latest data.

Related Products (ordered separately, Contact via email for confirmation):

Braking Resistor
Input Reactor
Output Reactor
EMC Filter
Communication Module (Profibus/DeviceNet/CANopen/Ethernet etc.)
I/O Extension Module
Control Panel (CDP 312R etc.)
Safety Function Board (AGPS-21C, ASTO etc.)

Official Documentation Reference:

ACS800-04/U4 Hardware Manual
ACS800 Firmware Manual
ACS800 Single Drives Catalog

6. Why Choose Us

Professional Procurement, Genuine ABB Quality Guaranteed — All ABB drives and spare parts obtained through professional procurement channels, ensuring genuine ABB original products with product identification, factory test reports, and quality documents, 12-month quality warranty. Pre-shipment appearance inspection, model confirmation, part number verification, and packaging check performed.
Worldwide Delivery, Professional Industrial Electronics Logistics — DHL/FedEx/UPS international courier, global delivery available. Industrial drives use shock-proof moisture-proof anti-static professional packaging, ensuring safe transport of IGBT modules, capacitors, control boards and other precision electronic components. Expedited logistics and customs clearance available, delivery to 200+ countries, meeting urgent project and maintenance needs.
Professional Technical Support, Full-process Service from Selection to Commissioning — Drive selection consultation (confirming motor power, current, voltage, load type, overload requirement, communication protocol, environmental condition matching), installation guidance (cabinet installation dimensions, wiring, grounding specifications, EMC requirements), parameter commissioning (application macro selection, motor ID run, PID tuning, communication configuration), fault diagnosis (overcurrent/overvoltage/overtemperature/ground fault cause analysis), and spare parts list review, helping users correctly select, install and maintain.
Flexible Procurement, Project Bulk and Spare Parts Framework Agreements — Single unit and bulk project orders, tiered discounts. Complete drive package solutions (drive + braking resistor + reactor + filter + communication module + control panel combination) and annual spare parts framework agreements available, helping users optimize procurement cost, ensure spare parts supply, minimize downtime risk. Customized quotations and long-term cooperation solutions available for OEM customers and system integrators.
Pre-shipment Verification, Test Report Available — Appearance, packaging, model, configuration checks before shipment; drive power-on test report available if necessary (basic function test, parameter reading, appearance inspection, accessory inventory), ensuring delivered product in good condition, accurate configuration, complete accessories. For urgent project needs (equipment retrofit, production line commissioning, fault repair), priority inventory coordination and expedited shipping available.

7. Frequently Asked Questions (FAQ)

Q1: What is ACS800-04N-12A6-4? What is the power? What applications is it used for?

A: The ACS800-04N-12A6-4 is a Single Drive Module from ABB's classic ACS800 series industrial drives, specifically designed for cabinet integration installation.

Basic info: Brand ABB (Switzerland), series ACS800, model ACS800-04N-12A6-4, product form Single Drive Module (cabinet installation, IP20), rated output current 12.6A, input voltage 380/400/415V AC three-phase ±10%, control technology DTC direct torque control, frame size R2, N option Conformal Coated PCBs for harsh environments.

What is the power?

Light-overload application (variable torque loads such as fans and pumps): typical motor power approx. 5.5kW
Heavy-duty application (constant torque/heavy-duty loads such as conveyors, mixers, hoists): typical motor power approx. 4kW
Specific power matching needs to be confirmed based on motor rated current, load characteristics, and overload requirements. We recommend providing motor nameplate parameters, and we can help confirm compatibility.

What applications is it used for? ACS800 series drives are widely used in almost all industrial motor speed control applications, including:

Fans, pumps, compressors and other fluid machinery speed control (energy-saving applications)
Conveyors, elevators, hoists and other material handling equipment
Mixers, grinders, centrifuges and other process machinery
Machine tools, textile machinery, printing machinery and other processing equipment
HVAC systems
Process control in petrochemical, natural gas, power, metallurgy, mining, cement, paper, water treatment, marine and other industries
N option (conformal coated) especially suitable for harsh environments with high humidity, corrosive gases, dust, such as petrochemical, chemical, metallurgy, mining, water treatment industries

Note: The ACS800-04 is an IP20 protected modular drive that must be installed in a control cabinet and cannot be directly installed in the field. If wall-mounted field installation is required, consider the ACS800-01 (IP21/IP55) series.

Q2: What is the difference between ACS800 and ACS880? Can I still buy ACS800 now?

A: Both ACS800 and ACS880 are ABB industrial drive series. The ACS880 is the new generation upgrade product of the ACS800.

ACS800 (Classic Series):

Launch: approx. 2003
Control technology: DTC Direct Torque Control
Communication: Standard Modbus, optional Profibus DP, DeviceNet, CANopen etc.
Safety functions: Optional +Q950 (Prevention of Unexpected Start-up), +Q967 (STO)
Panel: CDP 312R (round knob)
Status: Gradually discontinued/entering late lifecycle, but still a large number in operation worldwide, spare parts and some models still available
Advantages: Years of market verification, mature and reliable, huge global installed base, rich technical support resources, complete spare parts system

ACS880 (New Generation Series):

Launch: approx. 2013
Control technology: Enhanced DTC Direct Torque Control
Communication: Standard Modbus RTU/EIP, optional Profibus DP, Profinet, Ethernet/IP, CANopen etc., supporting more Ethernet protocols
Safety functions: Standard STO (Safe Torque Off), optional more safety functions (SS1, SSE, SLS etc.)
Panel: ACS-AP-S (Bluetooth smart assistant panel)
Status: Current main product, full series supply
Advantages: Newer hardware platform, stronger computing capability, more communication protocols, richer safety functions, more user-friendly commissioning tools, higher energy efficiency

Can I still buy ACS800 now?

The ACS800 series has been gradually succeeded by the ACS880, and some models may be discontinued. However, some ACS800 models (including this model ACS800-04N-12A6-4) can still be purchased through professional channels. Specific stock and lead time need to be confirmed by contacting via email.
For new projects, it is generally recommended to prioritize the new generation ACS880 series, with stronger performance, richer functions, and more stable supply.
For spare parts replacement, expansion, or same-model replacement needs of existing ACS800 equipment, purchasing ACS800 can maintain system consistency and reduce re-commissioning and training costs.
We can provide both ACS800 and ACS880 series products, and give appropriate selection recommendations based on your specific needs.

Q3: How to select a drive? How to confirm if this model can drive my motor?

A: Drive selection requires comprehensive consideration of motor parameters, load characteristics, application scenarios, environmental conditions, communication needs, and other factors. Here are the key selection points:

Confirm Motor Parameters:

Motor rated power (kW): Rated power indicated on the motor nameplate
Motor rated current (A): Rated current indicated on the motor nameplate — this is the most critical parameter for selection
Motor rated voltage (V): Usually 380V/400V/415V
Motor type: Asynchronous, synchronous, servo, high-speed, etc.
Motor insulation class: Affects tolerance to drive output dv/dt

Confirm Load Characteristics:

Variable torque load (fans, pumps, compressors): Low starting torque, operating torque varies with speed squared, generally select by light-overload, drive current slightly larger than motor rated current is sufficient
Constant torque load (conveyors, mixers, extruders): Torque basically constant over full speed range, need to select by heavy-duty, drive current needs sufficient margin
Potential energy load (hoists, elevators, lifts): Requires four-quadrant operation or braking resistor, high braking capability requirement
Overload requirement: Whether frequent starting, impact load, short-time overload is needed, overload multiple and duration

Confirm Drive Current Margin:

Basic principle: Drive rated output current ≥ Motor rated current × Safety factor
Light-overload applications (fans/pumps): Safety factor 1.0~1.1, drive current slightly larger than motor rated current is sufficient
Constant torque/heavy-duty applications: Safety factor 1.1~1.2, drive current needs 10~20% margin
Frequent starting/impact load: Safety factor 1.2~1.5, needs larger margin
This model ACS800-04N-12A6-4 rated current 12.6A, suitable for driving motors with rated current not exceeding approx. 11~12A (specific depends on load type)

Confirm Other Requirements:

Input voltage: Confirm whether site grid voltage is 380/400/415V (this model voltage class)
Environmental conditions: Temperature, humidity, altitude, corrosive gases, dust etc., harsh environments recommend N option (conformal coated) or higher protection degree
Communication protocol: What PLC/DCS to communicate with, confirm communication protocol (Profibus/Profinet/Ethernet/IP/Modbus etc.)
Safety functions: Whether STO, Prevention of Unexpected Start-up and other safety functions are needed
Braking requirement: Whether fast braking is needed, whether braking resistor is needed
EMC requirement: Whether input/output reactors, EMC filters are needed

How to confirm if this model can drive my motor? Please provide the following information, and we can help confirm:

Motor nameplate photo or complete parameters (power, current, voltage, speed, insulation class)
Load type (fan/pump/conveyor/mixer/hoist etc.)
Overload requirement and starting frequency
Site grid voltage and environmental conditions
Communication and safety function requirements

We will check whether the drive rated current, overload capability, and voltage class match based on the information you provide, and give clear selection confirmation and recommendations.

Q4: How to install and commission? What to pay attention to? Can I install it myself?

A: Installation and commissioning of ACS800 drives requires certain professional knowledge and skills, recommended to be performed by professional engineers trained in ABB drives.

Installation Key Points:

Cabinet installation: The ACS800-04 is an IP20 modular drive that must be installed in a control cabinet. Ensure the cabinet has sufficient installation space, ventilation/heat dissipation space, and maintenance space.
Mounting orientation: Must be vertically mounted, horizontal or inclined mounting is not allowed, ensure cooling air duct is unobstructed.
Installation spacing: When multiple units are installed side by side, maintain sufficient spacing (refer to hardware manual), ensure heat dissipation and maintenance space.
Environmental conditions: Cabinet internal temperature not exceeding 40°C (no derating), humidity 5~95% no condensation, avoid corrosive gases and dust.
Grounding: Must be reliably grounded, grounding resistance complies with specifications, motor cable shield 360° grounded, reduce EMI interference.
Wiring:
- Input power connected to drive input terminals (U1/V1/W1 or L1/L2/L3)
- Output connected to motor (U2/V2/W2 or T1/T2/T3), no capacitors allowed on output side, contactors on motor side need special handling
- Control signals connected to I/O terminals, note analog signal shielding
- Braking resistor connected to braking unit terminals (+/-BRK), note braking resistor power matching and temperature protection

Commissioning Key Points:

Pre-power check: Confirm wiring correct, no short circuit, reliable grounding, input voltage normal, motor disconnected from load (first commissioning recommend disconnecting load).
Power-on check: After power-on, check drive display normal, no fault alarm, fan running.
Parameter setting:
- Select application macro (Standard/PID/Torque etc.)
- Set motor parameters (rated voltage, current, power, speed, power factor, cosφ)
- Perform motor ID Run (motor identification), optimize motor model
- Set acceleration/deceleration time, torque limit, maximum frequency etc.
- Set I/O configuration, communication parameters, PID parameters (if needed)
No-load test: Motor disconnected from load, jog test motor rotation direction correct, gradually increase speed test operation smooth, no abnormal noise and vibration.
Load test: Connect load, gradually load test, observe current, torque, speed normal, confirm acceleration/deceleration, forward/reverse, PID regulation functions normal.
Parameter backup: After commissioning complete, backup parameters for maintenance and recovery.

Precautions:

Safety first: After drive power-off, DC bus capacitors still charged, need to wait at least 15 minutes (or confirm DC bus voltage drops to safe level) before opening cover for internal operation.
Output side taboos: No capacitors, power factor correction capacitors, surge absorbers allowed on drive output side; when contactor on output side, must close contactor before starting drive, not allowed to switch output contactor during drive operation.
Motor insulation: Motors driven by drives should withstand PWM voltage spikes (dv/dt) from drive output. Old motors or motors with low insulation class recommend installing output reactor or dv/dt filter.
Long cables: When motor cable length exceeds 50m (shielded) or 100m (unshielded), recommend installing output reactor.
EMC: In applications with high EMC requirements, recommend installing input reactor and EMC filter, motor cable use shielded cable and properly grounded.

Can I install it myself?

If you or your maintenance personnel have drive installation and commissioning experience, are familiar with electrical specifications and ABB drive parameter settings, you can install and commission yourself.
If no experience, strongly recommend contacting ABB official service or professional drive service provider for installation and commissioning, ensuring safety and correct operation.
First commissioning recommend disconnecting load, avoid equipment damage or safety accidents caused by parameter setting errors.

Q5: In stock? Lead time? Price?

A: Currently Order Available. The ACS800 series has gradually entered late lifecycle, some models have limited stock, specific stock fluctuates.

Lead time: Standard 4-8 weeks (ordering from ABB through professional channels or global stock allocation). Some common models may be in stock, specific subject to formal quotation. Some ACS800 models may be discontinued, need to confirm whether there are replacement models (such as ACS880 series).
Price: Subject to formal quotation, depends on quantity, supply channel, configuration options (communication module, I/O extension, safety functions etc.), whether includes technical service and commissioning support. Bulk procurement enjoys tiered discounts.
Alternative solution: If ACS800 model lead time is long or discontinued, we can provide replacement model recommendations from the new generation ACS880 series, with stronger performance, richer functions, and more stable supply. Replacement selection requires confirming installation dimensions, wiring, communication protocol, and parameter compatibility, we can provide a complete replacement solution.
Expedited service: For urgent needs (equipment failure downtime, production line commissioning emergency, project delivery deadline approaching), we can try to coordinate global stock or expedited ordering, please contact sales team.
Please indicate: motor power and current, load type, input voltage, communication protocol requirements, environmental conditions, required quantity, desired delivery time and destination when inquiring; we will coordinate fastest delivery and optimal price.
If you need to purchase supporting products simultaneously (braking resistor, input/output reactors, EMC filter, communication module, control panel etc.), we can provide complete package combined quotation with more favorable pricing, and annual spare parts framework agreement service.

ꄴPrevious： ABB ACS800-01-0040-3+P901+D150+N652 Industrial Drive | Wall-mounted 40A

ꄲNext： ABB 68766508 AGPS Retrofit Kit for R8i | AGPS-21C IGBT Gate Driver Power Board
