ABB MFE180-04AN-031A-4+L518+N8020 Servo Drive | 21A 480V

ABB MotiFlex e180 servo drive MFE180-04AN-031A-4, rated output current 21A RMS, apparent power 17.3kVA, input 200-480V three-phase, IP20 protection, air cooling, frame C. Configured with +L518 absolute encoder interface, +N8020 Mint motion programming, supports EtherCAT/EtherNet/IP etc., 200%-300% overload. Order available.

online consultation

Product Details

1. Product Overview

The ABB MFE180-04AN-031A-4+L518+N8020 is a medium-power model from ABB's MotiFlex e180 series high-performance servo drives, with rated output current 21A RMS, apparent power output 17.3 kV·A, input voltage 200-480V AC three-phase, protection degree IP20, air cooling, frame C, efficiency class IE2, standby loss 31W.

This model is configured with two key option codes:

+L518: Absolute Encoder Feedback — supports absolute encoder feedback, obtaining absolute motor position immediately upon power-up without homing. Absolute encoders maintain position information after power loss, immediately restoring position upon re-powering, significantly improving equipment startup efficiency and operational reliability, suitable for motion control applications requiring precise position positioning and multi-axis synchronization.
+N8020: Mint Motion Programming License — MINT (Multi-axis Intelligent Networked Technology) is ABB's high-level programming language specifically designed for motion control applications, simplifying the development of complex motion sequences. Equipped with a free Mint programming license, enabling simple positioning tasks, electronic gearing, electronic camming, multi-axis synchronization and other advanced motion control functions without additional motion controller, reducing system cost and complexity.

The MotiFlex e180 is ABB's new generation general-purpose servo drive, using advanced servo control algorithms to achieve high-precision position, speed and torque control of AC servo motors. The drive has built-in flexible Ethernet communication protocol options, selectable EtherCAT, EtherNet/IP, Modbus TCP, Ethernet Powerlink and other mainstream industrial Ethernet protocols, facilitating integration with various PLCs and motion controllers. Supports HIPERFACE DSL one-cable encoder solution, transmitting both power and encoder signals through one cable, reducing wiring cost and space.

This servo drive has strong overload capability, 200% overload for 3 seconds, 300% peak overload, capable of handling frequent acceleration/deceleration and impact loads in servo applications. Standard rich I/O interfaces, including 8 digital inputs (including 2 fast latch inputs at 1μs), 4 digital outputs, 2 analog inputs (12-bit, ±10V), 1 analog output (12-bit, ±10V), meeting signal connection needs for various motion control applications. I/O can be configured for drive functions (such as enable, limit switches, home sensors) or typical machine functions through Mint programming.

For safety functions, the MotiFlex e180 is standard equipped with 2-channel STO (Safe Torque Off) function, achieving SIL 3 / PL e safety level, meeting mechanical safety standard requirements, enabling safe stop without additional safety relays, reducing system cost and wiring complexity.

The MotiFlex e180 series servo drives are widely used in industrial fields requiring high-precision motion control, including packaging machinery, textile machinery, printing machinery, food & beverage machinery, pharmaceutical machinery, machine tools, robotics, electronic manufacturing equipment, automated assembly lines, material handling systems, etc. The 21A medium-power model is especially suitable for medium-power servo motor driving, such as large axis control, conveying mechanisms, positioning tables, lifting mechanisms, robot joints and other applications.

Note: This product is an ABB MotiFlex e180 series servo drive. Specific configuration (communication protocol, encoder type, I/O configuration, etc.) may vary depending on option codes. Some parameters are marked "Contact via email for confirmation." Installation, commissioning, and maintenance should be performed by professional engineers trained in ABB servo drives. Servo drives must be used with matching servo motors; ABB matching servo motors are recommended for best performance.

2. Specifications

表格

Parameter	Value
Brand	ABB (ABB Group, Switzerland)
Model	MFE180-04AN-031A-4+L518+N8020
Product Type	AC Servo Drive
Series	MotiFlex e180
Rated Output Current (In)	21 A RMS
Apparent Power Output	17.3 kV·A
Continuous Output Power	Approx. 10-12 kW (reference, subject to matching motor)
Peak Output Power	Approx. 20-24 kW (200% overload, reference)
Efficiency Class	IE2
Standby Loss	31 W
Input Voltage	200 ~ 480 V AC, three-phase
Input Frequency	48 ~ 63 Hz
Output Voltage	0 ~ input voltage (3-phase sinusoidal PWM)
Output Frequency	0 ~ 500 Hz
Control Method	Servo control (position/speed/torque control)
Overload Capability	200% for 3s; 300% peak (Contact via email)
Frame Size	C
Protection Degree	IP20
Cooling Method	Air cooling (A=Air cooling)
Option +L518	Absolute Encoder Feedback
Option +N8020	Mint Motion Programming License
Encoder Support	Absolute encoder (+L518); HIPERFACE DSL one-cable
Digital Inputs	8 (incl. 2 fast latch inputs at 1μs)
Digital Outputs	4
Analog Inputs	2 (12-bit, ±10V)
Analog Outputs	1 (12-bit, ±10V)
Standard Communication	Built-in Ethernet (selectable EtherCAT/EtherNet/IP/Modbus TCP/EPL)
Optional Communication	Contact via email (PROFIBUS, CANopen etc.)
Safety Function	2-channel STO (Safe Torque Off), SIL 3 / PL e
Operating Temperature	0 ~ +55°C (derating 2%/°C above 40°C)
Storage Temperature	-40 ~ +70°C
Transport Temperature	-40 ~ +70°C
Relative Humidity	Contact via email (no condensation)
Altitude	0 ~ 2000m (derating 1%/100m above 1000m)
Vibration	Contact via email (reference IEC 60068-2-6)
Control Power	Internal generated (Contact via email)
Dynamic Braking	Contact via email (requires external braking resistor)
Regenerative Braking	Contact via email (requires external braking unit/resistor)
Weight	Contact via email (frame C reference approx. 5-8kg)
Dimensions (H×W×D)	Contact via email (frame C reference)
Certifications	CE, UL, cUL, RoHS (Contact via email, subject to actual config)
Origin	Contact via email for confirmation (ABB global manufacturing)
HS Code	Contact via email for confirmation (reference 85044090)
Software	Mint Workbench (free programming/configuration software)
Stock Status	Order available
Warranty	12 months

3. Key Features

ABB MotiFlex e180 High-performance Servo Platform, High-precision Motion Control — The MotiFlex e180 is ABB's new generation general-purpose servo drive, using advanced servo control algorithms to achieve high-precision position, speed and torque control of AC servo motors. High control accuracy, fast response, smooth low-speed torque, suitable for industrial automation applications requiring precision motion control. The 21A medium-power model is suitable for medium-large axis control and high dynamic response applications.
+L518 Absolute Encoder Interface, Position on Power-up Without Homing — Configured with +L518 absolute encoder feedback interface, supporting absolute encoders, obtaining absolute motor position immediately upon power-up without homing. Absolute encoders maintain position information after power loss, immediately restoring position upon re-powering, significantly improving equipment startup efficiency and operational reliability, especially suitable for multi-axis synchronization, precision positioning and applications where homing cannot be performed.
+N8020 Mint Motion Programming, Built-in Intelligent Positioning — Configured with +N8020 Mint programming license, MINT (Multi-axis Intelligent Networked Technology) is ABB's high-level programming language specifically designed for motion control, simplifying development of complex motion sequences. Enables point-to-point motion, electronic gearing, electronic camming, multi-axis synchronization, trajectory planning and other advanced motion control functions without additional motion controller, reducing system cost and complexity, improving integration and reliability.
200%-300% Strong Overload Capability, Handling Impact Loads — The MotiFlex e180 has strong overload capability, 200% overload for 3 seconds, 300% peak overload, easily handling frequent acceleration/deceleration, short-term impacts and heavy-duty starting in servo applications. Advanced current control algorithms ensure smooth and precise output torque during overload without control performance degradation, suitable for packaging, printing, machine tools, robotics and other applications requiring frequent acceleration/deceleration and high dynamic response.
Built-in Multi-protocol Ethernet, Seamless Automation Integration — Built-in flexible Ethernet communication interface, selectable EtherCAT, EtherNet/IP, Modbus TCP, Ethernet Powerlink and other mainstream industrial Ethernet protocols, facilitating integration with various PLCs (such as ABB AC500, Siemens S7, Rockwell ControlLogix, Beckhoff, etc.) and motion controllers. High-speed real-time communication ensures multi-axis synchronization accuracy and control response speed, meeting communication needs of high-performance motion control applications.
2-channel STO Safety Function SIL3/PLe, Meeting Mechanical Safety Requirements — Standard equipped with 2-channel STO (Safe Torque Off) function, achieving SIL 3 / PL e safety level, meeting ISO 13849-1 and IEC 61508 mechanical safety standard requirements. STO function safely cuts off motor torque for safe stop without additional safety relays, reducing system cost and wiring complexity, improving safety system reliability and response speed.
Rich I/O Interfaces, Including 1μs Fast Latch Inputs — Standard rich I/O interfaces: 8 digital inputs (including 2 fast latch inputs at 1μs, suitable for high-speed position capture, flying shear, mark registration and other applications), 4 digital outputs, 2 analog inputs (12-bit resolution, ±10V), 1 analog output (12-bit, ±10V). I/O can be flexibly configured for drive functions or machine functions through Mint programming, meeting signal connection needs for various motion control applications.
HIPERFACE DSL One-cable Support, Reducing Wiring Cost — Supports HIPERFACE DSL (Digital Servo Link) one-cable encoder solution, transmitting both motor power and encoder signals through one cable, significantly reducing wiring quantity, cable cost and control cabinet space. One-cable solution also reduces wiring errors and improves system reliability, especially suitable for multi-axis systems and space-limited installation occasions.
Mint Workbench Free Software, Convenient Commissioning — Comes with Mint Workbench free programming/configuration software, providing intuitive graphical interface, supporting drive parameter configuration, motor auto-tuning, oscilloscope function, motion program writing and debugging, fault diagnosis and other functions. Built-in motor auto-tuning function automatically identifies motor parameters and optimizes control gains, shortening commissioning time. Oscilloscope function can real-time monitor position, speed, torque, current and other signals, convenient for debugging and fault analysis.
Wide Industrial Applications, Medium-power Precision Control Choice — The MotiFlex e180 series is widely used in packaging machinery, textile machinery, printing machinery, food & beverage machinery, pharmaceutical machinery, machine tools, robotics, electronic manufacturing equipment, automated assembly lines, material handling systems and other fields requiring high-precision motion control. The 21A medium-power model is especially suitable for medium-power servo motor driving, such as large axis control, conveying mechanisms, positioning tables, lifting mechanisms, robot joints, large feeding mechanisms and other applications.

5. Model Explanation

Product Model: MFE180-04AN-031A-4+L518+N8020

Product Description: ABB MotiFlex e180 series AC servo drive, rated output current 21A RMS, apparent power 17.3kVA, input 200-480V three-phase, IP20 protection, air cooling, frame C, configured with +L518 absolute encoder interface and +N8020 Mint motion programming

Model Breakdown:

表格

Component	Meaning
MFE180	ABB MotiFlex e180 series servo drive
04	Product type/mounting form (Contact via email, cabinet installation type)
A	Cooling method: A=Air cooling
N	Reserved (Reserved for future use)
031A	Model code, corresponding to rated output current 21A RMS
4	Input voltage: 200 ~ 480 V AC, three-phase
+L518	Option code: Absolute Encoder Feedback
+N8020	Option code: Mint Motion Programming License

MFE180 Series Explanation:

MFE180 = MotiFlex e180, ABB's new generation general-purpose AC servo drive
Distinguished from MicroFlex e150 (low power), MicroFlex e190 (medium-high power) and other servo drive series
Power range: 0.18kW ~ approx. 45kW (full series, different current ratings)
Voltage class: 200-480V AC three-phase
This model 21A/approx. 10-12kW belongs to medium power range

031A Current and Power Explanation:

Model code: 031A
Rated output current (In): 21 A RMS
Apparent power output: 17.3 kV·A
Continuous output power: approx. 10-12 kW (reference, subject to matching motor)
Peak output power: approx. 20-24 kW (200% overload, reference)
Overload capability: 200% for 3s, 300% peak
Efficiency class: IE2
Standby loss: 31W
Note: Servo drive power matching mainly depends on motor rated current and peak current, not simply power value. ABB matching servo motors are recommended for best performance.

Voltage Class 4 Explanation:

4 = 200 ~ 480 V AC, three-phase
Input frequency: 48~63Hz
Covers major industrial low-voltage grid voltages worldwide (200V Japan, 230V Europe, 380/400V China/Europe, 480V North America)
Wide voltage design, suitable for use in different regions worldwide

Frame C Explanation:

C = frame size number 3 in MFE180 series
Suitable for medium power range servo drives (13.5A, 21A, approx. 25A, etc.)
Compact structure, suitable for cabinet installation
Specific dimensions and weight: Contact via email for confirmation

Option Code Detailed Explanation:

+L518 — Absolute Encoder Interface

Full name: Absolute Encoder Feedback Module
Function: supports absolute encoder signal feedback
Features:
- Obtain absolute motor position immediately upon power-up, no homing needed
- Maintain position information after power loss, immediately restore upon re-powering
- Suitable for multi-axis synchronization, precision positioning applications
- Improve equipment startup efficiency and operational reliability
Other feedback options reference (+L5xx series):
- +L516 = Incremental Encoder
- +L518 = Absolute Encoder
- Other +L5xx options: Contact via email
Note: Encoder interface type must match the encoder type equipped on the servo motor

+N8020 — Mint Motion Programming Function

Full name: Mint Programming License
MINT = Multi-axis Intelligent Networked Technology
Functions:
- Built-in Mint motion control programming language
- Enable point-to-point motion, electronic gearing, electronic camming
- Multi-axis synchronization, trajectory planning
- Simple positioning tasks without additional motion controller
Features:
- Free Mint programming license
- Reduce system cost and complexity
- Improve integration and reliability
- Comes with Mint Workbench free programming/configuration software
Note: Mint programming function requires Mint Workbench software

MFE180 Series Common Model Comparison Reference:

表格

Model	Rated Output Current (In)	Continuous Power (ref)	Frame
MFE180-04AN-016A-4	1.6A	Approx. 0.18kW	A
MFE180-04AN-03A0-4	3A	Approx. 0.4kW	A
MFE180-04AN-05A0-4	5A	Approx. 0.75kW	A/B
MFE180-04AN-07A0-4	7A	Approx. 1kW	B
MFE180-04AN-024A-4	13.5A	Approx. 5.5-7.5kW	C
MFE180-04AN-031A-4	21A	Approx. 10-12kW	C
MFE180-04AN-060A-4	35A	Approx. 15-18kW	D
MFE180-04AN-090A-4	55A	Approx. 22-30kW	D

Note: The above comparison data comes from ABB public catalog and official product page, power values for reference only, specific subject to matching motor and official latest data.

Related Products (ordered separately, Contact via email for confirmation):

ABB matching servo motors (Baldor/ABB servo motor series)
Braking Resistor
Encoder Cable
Motor Power Cable
HIPERFACE DSL one-cable
Communication Cable (EtherCAT/Ethernet etc.)
Regenerative Unit
Input Filter
Reactor

Official Documentation Reference:

MotiFlex e180 User's Manual
MotiFlex e180 Catalog
Mint Workbench Help
MotiFlex e180 Common DC Application Guide
MotiFlex e180 STO Application Guide

6. Why Choose Us

Professional Procurement, Genuine ABB Quality Guaranteed — All ABB servo drives and spare parts obtained through professional procurement channels, ensuring genuine ABB original products with product identification, factory test reports, and quality documents, 12-month quality warranty. Pre-shipment appearance inspection, model confirmation, part number verification, option code verification, and packaging check performed.
Worldwide Delivery, Professional Industrial Electronics Logistics — DHL/FedEx/UPS international courier, global delivery available. Servo drives use shock-proof moisture-proof anti-static professional packaging, ensuring safe transport of IGBT modules, capacitors, control boards, encoder interfaces and other precision electronic components. Expedited logistics and customs clearance available, delivery to 200+ countries, meeting urgent project and maintenance needs.
Professional Technical Support, Servo Selection Commissioning Full-process Service — Servo drive selection consultation (confirming motor power, current, voltage class, encoder type, communication protocol, overload requirement matching), installation guidance (installation dimensions, wiring, grounding specifications, EMC requirements), parameter commissioning (motor auto-tuning, control gain optimization, communication configuration, Mint motion program writing), fault diagnosis (overcurrent/overvoltage/overtemperature/encoder fault cause analysis), and spare parts list review, helping users correctly select, install and maintain.
Flexible Procurement, Project Bulk and Spare Parts Framework Agreements — Single unit and bulk project orders, tiered discounts. Complete servo system package solutions (servo drive + servo motor + braking resistor + cables + filter combination) and annual spare parts framework agreements available, helping users optimize procurement cost, ensure spare parts supply, minimize downtime risk. Customized quotations and long-term cooperation solutions available for OEMs, system integrators, and end users.
Pre-shipment Verification, Test Report Available — Appearance, packaging, model, configuration, option code checks before shipment; servo drive power-on test report available if necessary (basic function test, parameter reading, encoder interface detection, appearance inspection, accessory inventory), ensuring delivered product in good condition, accurate configuration, complete accessories. For urgent project needs (equipment repair, production line retrofit, project commissioning), priority inventory coordination and expedited shipping available.

7. Frequently Asked Questions (FAQ)

Q1: What is MFE180-04AN-031A-4+L518+N8020? What is the rated current? What is the power?

A: The MFE180-04AN-031A-4+L518+N8020 is an ABB MotiFlex e180 series high-performance AC servo drive.

Basic info: Brand ABB (Switzerland), series MotiFlex e180, model MFE180-04AN-031A-4+L518+N8020, product type AC servo drive, rated output current (In) 21A RMS, apparent power output 17.3 kV·A, input voltage 200-480V AC three-phase, protection degree IP20, cooling method air cooling, frame C, efficiency class IE2, standby loss 31W.

What is the rated current?

Rated output current (In): 21A RMS
Note: "031A" in the model is the model code, not the rated current value. The actual rated output current is 21A (confirmed from ABB official product data).

What is the power?

Apparent power output: 17.3 kV·A
Continuous output power: approx. 10-12kW (reference value, specific subject to matching servo motor)
Peak output power: approx. 20-24kW (200% overload, reference value)
Overload capability: 200% for 3s, 300% peak
Note: Servo drive power matching mainly depends on motor rated current and peak current. ABB matching servo motors are recommended for best performance. The 21A model is suitable for driving medium-power servo motors with rated current approx. 14-18A (approx. 7.5-11kW).

What do the option codes mean?

+L518: Absolute Encoder Feedback, supporting absolute encoder feedback, obtaining absolute motor position immediately upon power-up without homing, maintaining position information after power loss, suitable for multi-axis synchronization and precision positioning applications.
+N8020: Mint Motion Programming License, MINT is ABB's high-level programming language specifically designed for motion control, enabling point-to-point motion, electronic gearing, electronic camming, multi-axis synchronization and other advanced motion control functions without additional motion controller.

Q2: What is the difference between servo drive and VFD? When to use servo drive?

A: Servo drives and VFDs are both motor control devices, but there are obvious differences in control accuracy, response speed, application scenarios, etc.

Servo Drive features:

High-precision position control: Servo drives can precisely control motor position, speed and torque, with position control accuracy up to encoder resolution level, suitable for applications requiring precise positioning.
Fast response: Servo drive current loop, speed loop, position loop control cycles are short (usually microseconds to milliseconds), with fast response speed, capable of quickly tracking command changes.
High overload capability: Servo drives usually have 200%-300% overload capability, capable of handling frequent acceleration/deceleration and impact loads.
Encoder feedback: Servo drives must be used with servo motors with encoders for closed-loop control.
Good low-speed performance: Servo drives can output smooth torque even at low speeds, and can maintain torque even at zero speed.
Higher price: Servo drives and servo motors are usually more expensive than VFDs and induction motors.
Typical applications: CNC machine tools, robotics, packaging machinery, printing machinery, electronic manufacturing equipment, automated assembly lines and other occasions requiring high-precision motion control.

VFD (Variable Frequency Drive) features:

Speed control mainly: VFDs mainly control motor speed, with lower position control accuracy (unless configured with encoder and positioning function).
Medium response speed: VFD control cycles are usually longer than servo drives, with medium response speed.
Lower overload capability: VFDs usually have 110%-150% overload capability.
Can run without encoder: VFDs can drive ordinary induction motors without encoders (V/F control or vector control), and can also be configured with encoders for closed-loop control.
Average low-speed performance: Ordinary VFDs may not output smooth torque at low speeds (vector control VFDs have better low-speed performance).
Lower price: VFDs and induction motors are usually cheaper than servo systems.
Typical applications: Fans, pumps, conveyors, mixers, hoists and other occasions mainly for speed control.

When to use servo drive?

Applications requiring precise position control (such as CNC machine tools, positioning tables, labeling machines)
Applications requiring fast response and high dynamic performance (such as robotics, flying shear, mark registration)
Applications requiring multi-axis synchronization (such as electronic gearing/camming in printing machinery, packaging machinery)
Applications requiring low-speed high torque and zero-speed torque holding
Applications with high requirements for control accuracy and repeat positioning accuracy
Applications with limited equipment space, requiring small size high power density

When to use VFD?

Only requiring speed control, no precise position control
Loads are fans, pumps and other variable torque loads
Cost-sensitive, no need for high-precision control
Motor power is large (tens of kW or more), servo system cost is too high
Low requirements for response speed

Simple judgment: If the application requires "positioning" or "synchronization", usually use servo drive; if only requiring "speed regulation", usually use VFD. This model MFE180 is a servo drive, suitable for high-precision motion control applications.

Q3: What is the difference between +L518 absolute encoder and incremental encoder? How to choose?

A: Absolute encoders and incremental encoders are the two most commonly used servo motor encoder types, each with features and applicable scenarios.

Absolute Encoder (+L518 configuration) features:

Position on power-up: Absolute encoders have unique code values for each position, immediately reading current absolute position upon power-up without homing.
Maintain position on power loss: Encoders still maintain position information (through internal battery or mechanical multi-turn structure), immediately restoring position upon re-powering.
No homing program needed: Equipment can directly enter working state after startup, no need to perform homing operation, improving startup efficiency.
Strong anti-interference: Absolute encoders output absolute position values, even if interference occurs during motion, position errors will not accumulate.
Multi-turn absolute: Multi-turn absolute encoders can record positions beyond one turn, suitable for applications requiring multi-turn position recording (such as screw drive, lifting mechanism).
Higher price: Absolute encoders are usually more expensive than incremental encoders.
More complex wiring: Absolute encoders (except HIPERFACE DSL one-cable) usually have more wiring than incremental encoders.
Typical applications: Multi-axis synchronization, precision positioning, applications where homing cannot be performed, applications requiring position maintenance after power loss.

Incremental Encoder features:

Homing needed on power-up: Incremental encoders output pulse signals, do not know current absolute position upon power-up, must perform homing program (finding home switch or encoder Z-phase signal) to determine position.
Lose position on power loss: Incremental encoders cannot maintain position information after power loss, must re-home upon re-powering.
Homing program needed: Equipment needs to perform homing operation first after startup, then enter working state, increasing startup time.
Possible accumulated errors: Incremental encoders calculate position by counting pulses, interference may cause pulse counting errors, thus accumulating position errors.
Single-turn/multi-turn: Incremental encoders usually only record relative displacement, need external counter to record multi-turn position.
Lower price: Incremental encoders are usually cheaper than absolute encoders.
Simple wiring: Incremental encoder wiring is usually simple (A/B/Z phase signals).
Typical applications: Speed control mainly, applications where homing can be performed, cost-sensitive applications.

How to choose?

Choose absolute encoder (+L518) when:
- Equipment cannot or is inconvenient to perform homing after startup
- Need to maintain position information after power loss
- Multi-axis synchronization applications, requiring all axes to work immediately upon simultaneous power-up
- Precision positioning applications, high requirements for position reliability
- Limited equipment working space, cannot install home switch
- Applications: CNC machine tools, robotics, printing machinery, electronic camming in packaging machinery, etc.
Choose incremental encoder when:
- Equipment can conveniently perform homing after startup
- Cost-sensitive, no need for position maintenance after power loss
- Speed control mainly, low position control requirements
- Applications: simple positioning tables, feeding mechanisms, etc.
Note: Encoder type must match the encoder type equipped on the servo motor. This model +L518 is configured with absolute encoder interface, must be used with servo motors equipped with absolute encoders. If your motor has an incremental encoder, you need to select +L516 or corresponding option.

Q4: What is +N8020 Mint programming for? Does it cost extra? What is the difference from PLC control?

A: +N8020 is the Mint motion programming function option for MotiFlex e180 servo drives.

What is +N8020 Mint programming for?

Built-in motion control: Mint is ABB's high-level programming language specifically designed for motion control, allowing users to write motion control programs inside the servo drive, achieving point-to-point motion, speed control, torque control and other basic functions.
Advanced motion functions: Through Mint programming, electronic gearing (GEAR), electronic camming (CAM), multi-axis synchronization, trajectory planning, flying shear, mark registration and other advanced motion control functions can be achieved.
I/O logic control: Mint programs can read and control drive I/O interfaces, achieving simple logic control, such as button input, limit switch processing, status output, etc.
No additional motion controller needed: For simple single-axis or few-axis positioning applications, with Mint programming function, the servo drive itself can complete motion control tasks without additional PLC or motion controller, reducing system cost.
Data processing and communication: Mint programs can perform data processing, arithmetic operations, communication protocol processing, etc., achieving data exchange with host computers.
Program storage: Mint programs are stored in the drive's internal non-volatile memory, automatically running upon power-up.

Does it cost extra?

This model +N8020 already includes Mint programming license, no extra cost.
Mint Workbench programming/configuration software is free, can be downloaded from ABB official website.
Note: Different +N8xx options may correspond to different Mint function levels. +N8020 is standard Mint programming function. If more advanced multi-axis synchronization or complex motion functions are needed, other options may be required, Contact via email for confirmation.

What is the difference from PLC control?

表格

Comparison	Mint Built-in Programming (+N8020)	PLC Control
Control location	Inside servo drive	External PLC
System cost	Low (no extra controller)	Higher (needs PLC and communication module)
Control cycle	Fast (drive level)	Medium (affected by PLC scan cycle and communication)
Multi-axis capability	Limited (usually single or few axes)	Strong (can control tens to hundreds of axes)
Logic control	Limited (simple logic)	Strong (complex logic, HMI, data processing)
Programming complexity	Medium (motion control specific language)	Medium (IEC61131 standard language)
Applicable scenarios	Single/few axes simple positioning	Complex multi-axis systems, complete automation lines
Maintenance convenience	Program in drive, replacement needs re-download	Program centralized in PLC, drive replacement convenient

Selection recommendations:

Use Mint built-in programming: Single-axis or 2-3 axis simple positioning applications, relatively simple equipment functions, cost-sensitive, no need for complex logic control. For example: single-axis positioning table, simple feeding mechanism, independent labeling unit, etc.
Use PLC control: Multi-axis (4+ axes) systems, need complex logic control, need HMI, need data acquisition and management, complex equipment functions. For example: fully automatic packaging lines, printing machinery, CNC machine tools, robotic systems, etc.
Hybrid solution: PLC + Mint hybrid solution can also be used, PLC responsible for system logic and coordination, Mint responsible for single-axis fine motion control and advanced motion functions (such as electronic camming), coordinated through EtherCAT or other buses.

Q5: In stock? Lead time? Price?

A: Currently Order Available. The MotiFlex e180 series is ABB's relatively new servo drive product, specific stock fluctuates.

Lead time: Standard 4-8 weeks (need to order from ABB through professional channels or global stock allocation). Some common models may be in stock, specific subject to formal quotation. Configurations with special options (+L518 absolute encoder, +N8020 Mint programming) may require factory assembly, longer lead time.
Price: Subject to formal quotation, depends on quantity, supply channel, option configuration (+L518 absolute encoder interface, +N8020 Mint programming function), whether includes technical service and commissioning support, whether matching servo motor and cables, etc. Bulk procurement enjoys tiered discounts.
Package solutions: We can provide complete servo system package solutions, including servo drive, matching servo motor, braking resistor, power cable, encoder cable, communication cable, filter, etc., combined procurement price more favorable.
Expedited service: For urgent needs (equipment repair, production line retrofit, project commissioning), we can try to coordinate global stock or expedited ordering, please contact sales team.
Please indicate: matching servo motor model and power, encoder type, communication protocol requirements, required quantity, desired delivery time and destination when inquiring; we will coordinate fastest delivery and optimal price.

ꄴPrevious： null

ꄲNext： ABB MFE180-04AN-016A-4+L518+N8020 Servo Drive | 1.6A 480V
