ABB PP875M 3BSE092982R1 7-inch Touch Panel
I. Product Overview
The ABB PP875M is a 7-inch black marine certified touch panel in the ABB Panel 800 series Human-Machine Interface (HMI) product line, with order number 3BSE092982R1. This touch panel is specifically designed for marine, offshore and harsh industrial environments, featuring a classic black panel appearance with marine certification, and is an important component of ABB's Compact Product Suite.
The PP875M is equipped with a 7-inch TFT-LCD widescreen display with 800×480 pixel resolution (16:9) and brightness up to 500cd/m², ensuring clear visibility in bright light environments. It features marine optimized dimming technology, with backlight brightness adjustable down to 0.5cd/m², adapting to low-light night environments such as ship bridges. The processor is ARM9 1GHz with 512MB main memory and 1.5GB application memory (SSD), equipped with an SD card slot for data storage and expansion. The touch panel uses resistive touch technology for accurate and reliable operation. Power supply is 24VDC (18-32VDC wide range), with operating temperature range of -10°C to +60°C, adapting to harsh environments. Product dimensions are 204×143×50mm, with a compact structure for convenient panel flush mounting. Widely used in human-machine interaction and equipment monitoring in marine propulsion systems, offshore platforms, industrial automation, process control and other fields.
II. Specifications
表格
| Parameter | Value |
|---|---|
| Brand | ABB |
| Model | PP875M |
| Order Number | 3BSE092982R1 |
| Product Series | Panel 800 Version 6.2 |
| Product Category | Black (marine certified panel) |
| Product Type | Touch Panel Human-Machine Interface (HMI) |
| Display Size | 7 inches |
| Display Type | TFT-LCD, LED backlight |
| Display Colors | 64K colors |
| Resolution | 800 × 480 pixels (16:9 widescreen) |
| Brightness | 500 cd/m² |
| Dimming | Marine optimized dimming, down to 0.5 cd/m² |
| Touch Type | Resistive touch |
| Processor | ARM9 (1GHz) |
| Main Memory | 512 MB |
| Application Memory | 1.5 GB (SSD) |
| External Storage | 1×SD card slot (supports SDHC) |
| Power Supply Voltage | 24 VDC (18-32 VDC wide range) |
| Power Consumption | Contact via email for confirmation |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | Contact via email for confirmation |
| Electrical Isolation | 1500 VAC (between communication ports and internal logic) |
| Protection Rating | Contact via email for confirmation |
| Dimensions (W×H×D) | 204 × 143 × 50 mm |
| Weight | Contact via email for confirmation |
| Mounting | Panel flush mounting |
| Marine Certification | Yes (Black marine certified) |
| Applicable Standards | IEC 60945 and other marine standards |
| Communication Interfaces | Contact via email for confirmation |
| Country of Origin | Contact via email for confirmation |
III. Product Features
- 7-inch TFT-LCD widescreen display with 800×480 resolution for clear and detailed images
- 500cd/m² high brightness display for clear visibility in bright light environments
- Marine optimized dimming technology, backlight adjustable down to 0.5cd/m² for low-light night environments
- Classic black panel appearance with marine certification for marine and offshore applications
- ARM9 1GHz processor with 512MB memory for smooth operation and fast response
- Resistive touch technology for accurate and reliable operation, supports gloved operation
- 24VDC wide range power supply (18-32VDC) for industrial power supply fluctuations
- Operating temperature -10°C to +60°C for harsh industrial and marine environments
- SD card slot for convenient data storage, backup and system expansion
- Compact structure with dimensions 204×143×50mm for convenient panel flush mounting
- 1500VAC electrical isolation for system safety and reliability
- Perfect compatibility with ABB System 800xA, Freelance and other control systems
IV. Typical Applications
- Marine propulsion system monitoring and operation
- Marine power station automation monitoring
- Offshore oil platform equipment monitoring
- Marine navigation and communication system HMI
- Marine cabin equipment monitoring
- Industrial automation production line human-machine interaction
- Process control system operator stations
- Water treatment equipment monitoring
- Energy management system display terminals
- HVAC system monitoring
V. Model Description
PP875M is the complete model number for the ABB Panel 800 series touch panel, with order number 3BSE092982R1. Model meaning:
- PP: Panel 800 series touch panel prefix (Panel Product)
- 8: Panel 800 series
- 75: 7-inch display size specification
- M: Marine certified version (black panel)
Other models in the same series include:
- PP875: 7-inch standard panel (3BSE092977R1, 350cd/m² brightness)
- PP875H: 7-inch high-performance marine panel (2GB memory)
- PP881: 10.1-inch standard panel
- PP886M: 15.4-inch marine certified panel
For detailed differences between models and selection recommendations, please contact via email for confirmation. We will provide detailed selection manuals and technical support.
VI. Why Choose Us
- Professional channel supply, comprehensive model coverage across multiple brands of industrial spare parts
- Strict quality inspection process ensuring reliable product quality
- Professional engineering team providing technical support and selection consultation
- Quick response, efficient logistics, orders accepted
- Quality assurance, worry-free after-sales service
VII. FAQ
Q1: What is the difference between PP875M and PP875?
A: The PP875M is the marine certified version (Marine), featuring a black panel, 500cd/m² brightness, marine optimized dimming (down to 0.5cd/m²) and marine certification; the PP875 is the standard version with 350cd/m² brightness and no marine certification. Both are 7-inch 800×480 resolution touch panels.
Q2: What is the operating temperature range of the PP875M?
A: The PP875M has an operating temperature range of -10°C to +60°C and a storage temperature of -20°C to +70°C, adapting to harsh industrial and marine environments.
Q3: What communication protocols does this touch panel support?
A: As a Panel 800 series product, the PP875M supports communication with ABB System 800xA, Freelance and other control systems. For specific communication interfaces and protocol configurations, please contact via email for confirmation, and we will provide detailed technical documentation.
Q4: What are the mounting dimensions of the PP875M?
A: The PP875M has external dimensions of 204×143×50mm (W×H×D) and uses panel flush mounting. For specific cutout dimensions, please refer to the product installation manual. For detailed installation drawings, please contact via email for confirmation.
