Schneider ATS22D62Q Altistart 22 Soft Starter 62A

Schneider ATS22D62Q Altistart 22 soft starter, Schneider Electric ATS22 series, line rating 62A, control voltage 220V, supply 230V/15kW to 400~440V/30kW (up to 55kW in delta), 3-phase, slim design, used for soft starting and soft stopping of asynchronous motors, smooth starting avoiding mechanical stress, widely used in industrial drive systems.

online consultation

Product Details

I. Product Overview

The Schneider ATS22D62Q is a soft starter from the Altistart 22 series manufactured by Schneider Electric of France, model ATS22D62Q. This soft starter has a line rating of 62A, control voltage of 220V, supply voltage 230~440V, suitable for 15kW motors at 230V and 30kW motors at 400~440V (up to 55kW when connected in motor delta), used for soft starting and soft stopping of three-phase asynchronous motors.

The Altistart 22 (ATS22) is Schneider Electric's classic soft starter series, covering 4~400kW, designed for three-phase squirrel-cage asynchronous motors, achieving smooth start/stop via voltage and torque control. The ATS22D62Q has a factory setting current of 57A, power dissipation of 59W in standard applications, utilization category AC-53A, torque-controlled starting (current limited to 3.5 In), and class 10 motor protection in standard applications. It features 4 LEDs, 4 navigation keys and a 4-digit display, supporting SoMove software configuration via Bluetooth or cable.

The ATS22D62Q has a control voltage of 220V, three-phase application, protection rating IP20. The line rating is 62A at supply voltage 230~440V. This soft starter can be connected in the motor supply line (inline) or in the motor delta (inside delta), with power up to 55kW (400~440V) in delta connection. Integrated Modbus communication; optional Fipio, PROFIBUS DP, DeviceNet, Modbus TCP. This product is nearing end of life (EOL May 2027, EoS May 2035). It is widely used in pumps, fans, conveyors, compressors and other industrial drive applications.

II. Specifications

表格

Parameter	Value
Brand	Schneider Electric (France)
Model	ATS22D62Q
Product Type	Soft Starter
Series	Altistart 22 (ATS22)
Line Rating	62 A
Factory Setting Current	57 A
Control Voltage	220 V
Supply Voltage	230~440 V (-15%~+10%)
Motor Power (Inline)	15kW at 230V; 30kW at 400~440V
Motor Power (Delta)	55kW at 400~440V
Phases	3-phase
Utilization Category	AC-53A
Starting Method	Torque-controlled start (current limited to 3.5 In)
Motor Protection	Class 10 in standard applications
Power Dissipation	59 W (standard applications)
Protection Rating	IP20
Display	4 LEDs + 4-digit display + 4 navigation keys
Configuration Software	SoMove (Bluetooth/cable)
Communication	Integrated Modbus; optional Fipio/PROFIBUS DP/DeviceNet/Modbus TCP
Main Function	Soft start/soft stop for asynchronous motors
Starting Feature	Smooth starting, avoids mechanical stress
Design Feature	Slim form factor
Status	End of Life approaching (EOL May 2027)
Applicable Motor	Three-phase squirrel-cage asynchronous motor
Typical Loads	Pumps, fans, conveyors, compressors
Standards	IEC/EN 60947-4-2, UL, CSA, C-Tick
Manufacturer	Schneider Electric (France)

III. Product Features

Schneider Altistart 22 soft starter
Model ATS22D62Q, line rating 62A
Control voltage 220V, supply 230~440V
Suitable for 15~30kW inline / 55kW delta motors
Soft start/soft stop, smooth starting
Torque control, current limited to 3.5 In
Avoids mechanical stress, extends equipment life
Reduces starting current, minimizes grid shock
Slim design for mounting versatility
Integrated Modbus, multiple fieldbus options
SoMove Bluetooth/cable configuration
4-digit display with LED indication
Class 10 motor protection in standard applications

IV. Typical Applications

Water pump soft start control
Fan soft starting
Conveyor drives
Compressor soft starting
Crushers and mixers
Conveying equipment
Industrial pumps and fans
Three-phase asynchronous motor start control

V. Model Description

The ATS22D62Q fields are explained as follows:

ATS22: Schneider Altistart 22 soft starter series
D: Design/size code
62: Line rating 62A
Q: Control voltage code (220V)

Note: This product is nearing end of life (EOL May 2027, EoS May 2035). This soft starter supports both inline connection and motor delta connection. To confirm bypass contactor, terminal configuration and other details, please contact via email for confirmation. We will provide technical documentation and selection support.

VI. Why Choose Us

Professional channel supply, comprehensive model coverage across multiple brands of industrial spare parts
Strict quality inspection process ensuring reliable product quality
Professional engineering team providing technical support and selection consultation
Quick response, efficient logistics, orders accepted
Quality assurance, worry-free after-sales service

VII. FAQ

Q1: What is ATS22D62Q?

A: ATS22D62Q is a Schneider Altistart 22 series soft starter, line rating 62A, control voltage 220V, suitable for 15~30kW three-phase asynchronous motors.

Q2: What are the key parameters of this soft starter?

A: Line rating 62A, control voltage 220V, supply 230~440V, 15kW at 230V / 30kW at 400~440V (55kW in delta), 3-phase, IP20, integrated Modbus.

Q3: Is this product discontinued?

A: This product is nearing end of life (EOL May 2027, EoS May 2035); please contact via email for details.

Q4: How to confirm this soft starter's compatibility with the existing motor?

A: Please provide the existing motor power, rated voltage and rated current, contact via email, and we will assist in confirming compatibility and provide technical documentation.
