Schneider ATS48D75Q Altistart 48 Soft Starter 69A

Schneider ATS48D75Q Altistart 48 soft starter, Schneider Electric ATS48 series, line rating 69A, control voltage 220V, supply 230~415V, heavy duty 15~30kW/standard 18.5~55kW, 3-phase, TCS torque control, optional external bypass, used for soft starting and soft stopping of asynchronous motors, smooth starting avoiding mechanical stress, widely used in industrial drive systems.

online consultation

Product Details

I. Product Overview

The Schneider ATS48D75Q is a soft starter from the Altistart 48 series manufactured by Schneider Electric of France, model ATS48D75Q. This soft starter has a line rating of 69A, control voltage of 220V, supply voltage 230~415V, suitable for 15~30kW in heavy duty and 18.5~55kW in standard duty three-phase asynchronous motors, used for soft starting and soft stopping, achieving smooth motor start, reducing starting current and avoiding mechanical shock.

The Altistart 48 (ATS48) is Schneider Electric's premium soft starter series, designed for heavy industry and pump applications, covering 4~1200kW. This series features TCS (Torque Control System), achieving smooth start/stop via both voltage and torque control, supporting standard and heavy duty applications. The ATS48D75Q has utilization category AC-53A, supports optional external bypass, and provides comprehensive motor protection.

The ATS48D75Q is a three-phase application with protection rating IP20. This soft starter can be connected in the motor supply line (inline) or in the motor delta (inside delta), with inside delta connection supporting up to 55kW. Communication is Modbus (RS485, RJ45, baud rate 4800/9600/19200bps). It supports 5 logic inputs (including PTC probe 750Ω), 2 logic outputs and 3 relay outputs (fault, end of start, motor energized), with analog current output 0-20mA/4-20mA. Dimensions 190×235×290mm, net weight 8.3kg. It is widely used in pumps, fans, compressors and other applications.

II. Specifications

表格

Parameter	Value
Brand	Schneider Electric (France)
Model	ATS48D75Q
Product Type	Soft Starter
Series	Altistart 48 (ATS48)
Line Rating (Standard/Heavy Duty)	69 A
Control Voltage	220 V (50/60Hz)
Supply Voltage	230~415 V (-15%~+10%)
Motor Power	Heavy duty: 230V/15kW, 400V/30kW; Standard: 230V/18.5kW, 400V/37kW; inside delta up to 55kW
Phases	3-phase
Utilization Category	AC-53A
Start Control	TCS Torque Control System (current limited to 5 In)
Bypass	External bypass (optional)
Protection Rating	IP20
Power Dissipation	201W (heavy duty) / 245W (standard)
Logic Inputs	5 (Stop, Run, LI3, LI4), PTC probe 750Ω supported
Logic Outputs	2 (0V common, configurable)
Relay Outputs	3 (fault NO, end of start NO, motor energized NO)
Analog Output	Current output 0-20mA / 4-20mA
Communication	Modbus (RS485, RJ45, 4800/9600/19200bps)
Supply Frequency	50/60Hz (-5%~+5%)
Operating Temperature	-10~40°C (without derating); 40~60°C (2%/°C derating)
Storage Temperature	-25~70°C
Humidity	0~95% (non-condensing)
Operating Altitude	≤1000m (no derating); >1000~2000m (2.2%/100m derating)
Mounting Position	Vertical ±10°
Dimensions	190 (W) × 235 (D) × 290 (H) mm
Net Weight	8.3 kg
Protection Functions	Phase loss, motor thermal, starter thermal
Standard	EN/IEC 60947-4-2
Approvals	TCF, CSA, DNV, UL, C-Tick, NOM 117, CCC, SEPRO, GOST, CE
Applicable Motor	Three-phase squirrel-cage asynchronous motor
Typical Applications	Heavy industry, pumps, fans, compressors
Manufacturer	Schneider Electric (France)

III. Product Features

Schneider Altistart 48 soft starter
Model ATS48D75Q, line rating 69A
Control voltage 220V, supply 230~415V
Suitable for 15~55kW motors
TCS torque control system, smooth start/stop
Supports standard and heavy duty applications
External bypass design (optional)
Pump soft stop function, avoids water hammer
Avoids mechanical stress, extends equipment life
Reduces starting current, minimizes grid shock
Rich IO interfaces with Modbus communication
Comprehensive motor protection
Suitable for heavy industry applications

IV. Typical Applications

Water pump soft start and soft stop control
Fan soft starting
Conveyor drives
Compressor soft starting
Crushers and mixers
Conveying equipment
Heavy industrial drives
Three-phase asynchronous motor start control

V. Model Description

The ATS48D75Q fields are explained as follows:

ATS48: Schneider Altistart 48 soft starter series
D: Supply voltage code (230~415V)
75: Model code (line rating 69A)
Q: Control voltage code (220V)

Note: This soft starter supports both inline connection and motor delta connection, with external bypass optional. To confirm bypass contactor, control voltage, terminal configuration and other details, please contact via email for confirmation. We will provide technical documentation and selection support.

VI. Why Choose Us

Professional channel supply, comprehensive model coverage across multiple brands of industrial spare parts
Strict quality inspection process ensuring reliable product quality
Professional engineering team providing technical support and selection consultation
Quick response, efficient logistics, orders accepted
Quality assurance, worry-free after-sales service

VII. FAQ

Q1: What is ATS48D75Q?

A: ATS48D75Q is a Schneider Altistart 48 series soft starter, line rating 69A, control voltage 220V, suitable for 15~55kW three-phase asynchronous motors.

Q2: What are the key parameters of this soft starter?

A: Line rating 69A, control voltage 220V, supply 230~415V, heavy duty 15~30kW / standard 18.5~55kW, 3-phase, IP20, TCS torque control, Modbus communication, net weight 8.3kg.

Q3: What protection functions does this soft starter have?

A: It has phase loss protection, motor thermal protection and starter thermal protection, supporting PTC motor temperature probe input.

Q4: How to confirm this soft starter's compatibility with the existing motor?

A: Please provide the existing motor power, rated voltage and rated current, contact via email, and we will assist in confirming compatibility and provide technical documentation.
