GE Fanuc IC200ALG630 Thermocouple Analog Input Module
I. Product Overview
The GE Fanuc IC200ALG630 is a VersaMax PLC system thermocouple analog input module from GE Fanuc (General Electric Fanuc), model IC200ALG630. This module is a 7 channel thermocouple input device, 16-bit resolution, supports multiple thermocouple types, used for industrial automation system temperature measurement and control.
VersaMax is the programmable controller system from GE Fanuc, widely used in manufacturing, process control and industrial automation fields. The IC200ALG630 as a system input module provides 7 channel thermocouple temperature measurement function.
The IC200ALG630 is a DIN rail-mounted analog input module.
II. Specifications
表格
| Parameter | Value |
|---|---|
| Brand | GE Fanuc (USA) |
| Model | IC200ALG630 |
| Order Code | IC200ALG630 |
| Product Type | Thermocouple Analog Input Module |
| Series | VersaMax PLC |
| Input Channels | 7 channel thermocouple input |
| Resolution | 16-bit (15 bits plus sign) |
| Thermocouple Types | J, K, T, S, R |
| Input Types | Thermocouple, millivolt |
| Update Rate | 60ms/channel (60Hz), 70ms/channel (50Hz) |
| Temperature Accuracy | ±0.15% (25°C) |
| Voltage Accuracy | ±0.2% (25°C) |
| Power Consumption | 125 mA (+5V bus) |
| Operating Temperature | 0-60°C |
| LED Indicators | OK |
| Isolation | 250VAC continuous, 1500VAC for 1 minute |
| Mounting | DIN rail mounting |
| Typical Applications | Industrial temperature measurement, process control, manufacturing |
| Manufacturer | GE Fanuc |
III. Product Features
- GE Fanuc VersaMax PLC system thermocouple analog input module
- Model IC200ALG630, 7 channel thermocouple input
- 16-bit resolution
- Supports J/K/T/S/R type thermocouples
- 60ms/channel update rate
- DIN rail mounting
- Used for industrial temperature measurement and control
- Provides 7 channel thermocouple temperature measurement function
- Suitable for process control and manufacturing
- Widely used in industrial automation systems
IV. Typical Applications
- Industrial temperature measurement and control
- Process control system temperature acquisition
- Manufacturing production line temperature monitoring
- Equipment temperature monitoring
- Oven/furnace temperature control
- Industrial equipment temperature signal input
V. Model Description
The IC200ALG630 fields are explained as follows:
- IC200: VersaMax series PLC module series number
- ALG: Analog input module type
- 630: 7 channel thermocouple input, 16-bit resolution
Note: This module is a VersaMax PLC system thermocouple analog input module. To confirm wiring method, configuration parameters and other details, please contact via email for confirmation. We will provide technical documentation and selection support.
VI. Why Choose Us
- Professional channel supply, comprehensive model coverage across multiple brands of industrial spare parts
- Strict quality inspection process ensuring reliable product quality
- Professional engineering team providing technical support and selection consultation
- Quick response, efficient logistics, orders accepted
- Quality assurance, worry-free after-sales service
VII. FAQ
Q1: What is IC200ALG630?
A: IC200ALG630 is a GE Fanuc VersaMax PLC system thermocouple analog input module, 7 channel thermocouple input, 16-bit resolution, used for industrial automation system temperature measurement and control.
Q2: What are the key parameters of this module?
A: 7 channel thermocouple input, 16-bit resolution, supports J/K/T/S/R type thermocouples, 60ms/channel update rate, DIN rail mounting.
Q3: What features does this module have?
A: Provides 7 channel thermocouple temperature measurement function, 16-bit resolution. For detailed functions, please contact via email.
Q4: How to confirm this module's compatibility with the existing PLC system?
A: Please provide the existing PLC system model and temperature measurement requirements parameters, contact via email, and we will assist in confirming compatibility and provide technical documentation.
