GE Fanuc IC200ALG321 Analog Voltage Output Module
I. Product Overview
The GE Fanuc IC200ALG321 is a VersaMax PLC system analog voltage output module from GE Fanuc (General Electric Fanuc), model IC200ALG321. This module is a 4 channel analog voltage output device, output range 0-10.24VDC, 12-bit resolution, used for industrial automation system analog signal output control.
VersaMax is the programmable controller system from GE Fanuc, widely used in manufacturing, process control and industrial automation fields. The IC200ALG321 as a system output module provides 4 channel analog voltage output function.
The IC200ALG321 is a DIN rail-mounted analog output module.
II. Specifications
表格
| Parameter | Value |
|---|---|
| Brand | GE Fanuc (USA) |
| Model | IC200ALG321 |
| Order Code | IC200ALG321 |
| Product Type | Analog Voltage Output Module |
| Series | VersaMax PLC |
| Output Channels | 4 single-ended analog voltage outputs |
| Output Range | 0-10.24 VDC |
| Resolution | 12-bit (2.5mV/bit) |
| Accuracy | ±0.3% typical, ±1% max (full scale) |
| Update Rate | 0.3 ms (max) |
| Channel Crosstalk Rejection | ≥70 dB |
| Load Capacity | ≥5000Ω resistive, ≤1µF capacitive |
| Power Consumption | 50 mA (+5V bus) |
| Current Consumption | 210 mA (max, including load current) |
| LED Indicators | FLD PWR, OK |
| Mounting | DIN rail mounting |
| Typical Applications | Industrial automation, process control, manufacturing |
| Manufacturer | GE Fanuc |
III. Product Features
- GE Fanuc VersaMax PLC system analog voltage output module
- Model IC200ALG321, 4 channel analog voltage output
- Output range 0-10.24VDC
- 12-bit resolution, 2.5mV/bit
- 0.3ms update rate
- DIN rail mounting
- Used for industrial automation analog signal output control
- Provides 4 channel analog voltage output function
- Suitable for manufacturing and process control
- Widely used in industrial automation systems
IV. Typical Applications
- Industrial automation analog signal output control
- Manufacturing production line process control
- Process control system analog output
- Valve opening control signal output
- VFD frequency reference signal output
- Industrial equipment analog control signal output
V. Model Description
The IC200ALG321 fields are explained as follows:
- IC200: VersaMax series PLC module series number
- ALG: Analog output module type
- 321: 4 channel analog voltage output (0-10.24VDC)
Note: This module is a VersaMax PLC system analog voltage output module. To confirm wiring method, configuration parameters and other details, please contact via email for confirmation. We will provide technical documentation and selection support.
VI. Why Choose Us
- Professional channel supply, comprehensive model coverage across multiple brands of industrial spare parts
- Strict quality inspection process ensuring reliable product quality
- Professional engineering team providing technical support and selection consultation
- Quick response, efficient logistics, orders accepted
- Quality assurance, worry-free after-sales service
VII. FAQ
Q1: What is IC200ALG321?
A: IC200ALG321 is a GE Fanuc VersaMax PLC system analog voltage output module, 4 channel analog voltage output, 0-10.24VDC, used for industrial automation system analog signal output control.
Q2: What are the key parameters of this module?
A: 4 channel analog voltage output, output range 0-10.24VDC, 12-bit resolution, 0.3ms update rate, DIN rail mounting.
Q3: What features does this module have?
A: Provides 4 channel analog voltage output function, 12-bit resolution, fast update. For detailed functions, please contact via email.
Q4: How to confirm this module's compatibility with the existing PLC system?
A: Please provide the existing PLC system model and expansion requirements parameters, contact via email, and we will assist in confirming compatibility and provide technical documentation.
