GE FDS36TD040ED 430169 Molded Case Circuit Breaker 40A 3P 36kA MCCB
I. Product Overview
The GE FDS36TD040ED is a molded case circuit breaker (MCCB) from the Record Plus series manufactured by GE (General Electric), USA. It belongs to the FDS160 frame class, with rated current 40A and 3 poles. The breaker adopts advanced current-limiting technology and modular design, with rated operational voltage 690VAC/500VDC and breaking capacity 36kA (415VAC), suitable for overload and short-circuit protection of industrial and commercial power distribution circuits.
The Record Plus series is GE's widely applied molded case circuit breaker platform in the global market, covering current ratings from 16A to 1600A, featuring high breaking capacity, reliable protection characteristics and flexible mounting arrangements. The FDS160 frame breaker is suitable for distribution circuits up to 160A, and can be used in distribution boards, control panels, power distribution boxes and other applications, serving as main circuit protection or equipment protection circuit breaker.
The FDS36TD040ED is equipped with an LTMD enhanced selective thermal-magnetic trip unit, with thermal trip setting range of 0.8×In to In (adjustable) and fixed magnetic trip setting, providing both overload and short-circuit protection suitable for various load characteristics. The breaker features a thermosetting molded case (plastic housing), with good insulation performance and high mechanical strength, compliant with IEC 60947-2 and GB 14048.2 international/national standards.
II. Specifications
表格
| Parameter | Value |
|---|---|
| Brand | GE (General Electric) |
| Series | Record Plus |
| Model | FDS36TD040ED |
| Order Code | 430169 |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Frame Class | FDS160 (160A frame) |
| Rated Current In | 40A |
| Number of Poles | 3P (3-pole) |
| Rated Operational Voltage Ue | 690VAC / 500VDC |
| Breaking Capacity Icu | 36kA (415VAC) |
| Trip Unit Type | LTMD enhanced selective thermal-magnetic |
| Thermal Trip Setting | 0.8×In ~ In (adjustable) |
| Magnetic Trip Setting | Fixed (contact via email for confirmation) |
| Rated Insulation Voltage Ui | Contact via email for confirmation |
| Rated Impulse Withstand Voltage Uimp | Contact via email for confirmation |
| Utilization Category | Contact via email for confirmation |
| Mounting Method | Fixed mounting (front panel connection) |
| Connection Method | Contact via email for confirmation |
| Weight | Approx. 1.25kg |
| Applicable Standards | IEC 60947-2, GB 14048.2 |
| Approvals | CE, etc. (contact via email for confirmation) |
| Country of Origin | Contact via email for confirmation |
III. Product Features
- GE brand, mature Record Plus series molded case circuit breaker platform, stable and reliable performance
- FDS160 frame, 160A frame class, suitable for various distribution circuits
- Rated current 40A, 3-pole design, standard three-phase circuit configuration
- Rated operational voltage 690VAC/500VDC, wide application range
- Breaking capacity 36kA (415VAC), strong short-circuit protection capability
- LTMD enhanced selective thermal-magnetic trip unit, thermal trip adjustable 0.8×In~In, adaptable to different loads
- Integrated overload and short-circuit protection, complete protection characteristics
- Thermosetting molded case, good insulation performance, high mechanical strength
- Current-limiting design, quick interruption, protecting equipment safety
- Compliant with IEC 60947-2 and GB 14048.2 standards
- Suitable for overload and short-circuit protection in industrial and commercial distribution systems
- Applicable in distribution boards, control panels, power distribution boxes and other applications
IV. Typical Applications
- Overload and short-circuit protection of industrial distribution boards/panels
- Power distribution protection for commercial building electrical systems
- Short-circuit and overload protection for motor circuits
- Main circuit protection for power distribution systems
- Secondary circuit protection for control panels and switchgear
- Power supply protection for machinery electrical control systems
- Distribution protection for building electrical and building automation
- Electrical system protection for marine and special applications (contact via email for confirmation)
- Overload, short-circuit isolation and protection for various low-voltage distribution circuits
V. Model Description
FDS36TD040ED is the complete model number for the GE Record Plus series molded case circuit breaker, with the following field meanings:
- FDS: GE Record Plus series MCCB frame code (FDS160 frame, 160A frame class)
- 36: Breaking capacity class code (Icu 36kA @ 415VAC)
- T: Trip unit type (Thermal-Magnetic)
- D: Trip unit configuration code (LTMD enhanced selective thermal-magnetic protection)
- 040: Rated current code (40A)
- E: Poles/version code (3-pole, contact via email for confirmation)
- D: Version/terminal and other configuration code (contact via email for confirmation)
Order code 430169 is the corresponding GE standard ordering code for FDS36TD040ED. For the complete meaning of the E, D suffix codes (terminal type, mounting arrangement, etc.) and detailed breaking capacity parameters at different voltages, please contact via email for confirmation. We will provide detailed selection information and technical support.
VI. Why Choose Us
- Professional channel supply, comprehensive model coverage across multiple brands of industrial spare parts
- Strict quality inspection process ensuring reliable product quality
- Professional engineering team providing technical support and selection consultation
- Quick response, efficient logistics, orders accepted
- Quality assurance, worry-free after-sales service
VII. FAQ
Q1: What are the rated current and number of poles of FDS36TD040ED?
A: The rated current of FDS36TD040ED is 40A with 3 poles (3P), suitable for three-phase distribution circuits. This breaker belongs to the FDS160 frame class and can meet the overload and short-circuit protection requirements of 40A class distribution circuits.
Q2: What is the breaking capacity of this breaker?
A: The breaking capacity of FDS36TD040ED is 36kA (415VAC). The breaking capacity values at different voltage levels may vary. For specific breaking parameters at 380V/400V/690V and other voltages, please contact via email for confirmation.
Q3: How is the trip unit of this breaker set?
A: FDS36TD040ED is equipped with an LTMD enhanced selective thermal-magnetic trip unit. The thermal trip setting range is 0.8×In to In (adjustable between 32A and 40A), and the magnetic trip (short-circuit protection) is fixed setting. For the factory default settings, please contact via email for confirmation.
Q4: Can this breaker replace molded case circuit breakers of the same specification from other brands?
A: FDS36TD040ED is an IEC standard 3-pole 40A molded case circuit breaker. As long as the mounting dimensions (such as front panel connection distance, mounting hole spacing, etc.) and electrical parameters (rated current, breaking capacity, voltage class) meet the circuit requirements, it can be used as a replacement option for similar 3P 40A MCCBs. However, it is recommended to verify mounting dimensions, terminal type and breaking capacity compatibility before replacement. For any questions, please contact via email.
