Emerson TREX2CHPNAWS1S AMS Trex Device Communicator

The Emerson AMS Trex handheld device communicator (HART field communicator), with HART protocol, rechargeable Li-ion battery, Bluetooth wireless, 5.7-inch touchscreen and intrinsic safety, for configuring and maintaining smart positioners/transmitters.

online consultation

Product Details

1. Product Overview

TREX2CHPNAWS1S is the Emerson AMS Trex™ Device Communicator, the next-generation handheld field communicator replacing the 475. Built on an embedded Android platform, it configures, trims, diagnoses and maintains smart transmitters, valve positioners and level/pressure/temperature instruments over HART.

By part-number configuration: H = HART application, P = rechargeable Li-ion power module, W = wireless (Bluetooth); the redesigned AMS Trex adds HART over Bluetooth to connect field devices wirelessly and run an expanded app library. It has a 5.7-inch color VGA resistive touchscreen, quad-core processor, 64 GB storage, intrinsic safety (ATEX/IECEx/CSA Ex ia IIC T4), IP54 and 8+ hours of battery use.

2. Specifications

表格

Item	Specification
Manufacturer	Emerson
Model	AMS Trex Device Communicator
Order number	TREX2CHPNAWS1S
Product type	Handheld HART device communicator
Protocol	HART (H config)
Wireless	Bluetooth (W config), HART over Bluetooth
Power module	Rechargeable Li-ion (P config)
Processor	1.2 GHz quad-core Cortex-A53 / NXP i.MX 8M Mini
Memory	64 GB NAND flash; 4 GB LPDDR4 SDRAM
Display	5.7 in (14.5 cm) color VGA resistive touchscreen
Battery life	8+ hours typical
Operating temp.	−20 to +55 °C
Enclosure rating	IP54
Hazardous-area cert.	ATEX / IECEx / CSA Ex ia IIC T4 (intrinsic safety)
Weight	~1.33 kg (2.9 lb)

5. Model Information

Order number: TREX2CHPNAWS1S
Model: AMS Trex Device Communicator
Product description: Emerson AMS Trex handheld HART communicator, rechargeable Li-ion, Bluetooth wireless.
Material number note: In the order number, H = HART, P = rechargeable Li-ion, W = wireless (Bluetooth); the remaining letters encode certification and support level. For FOUNDATION Fieldbus, different certs or support, please provide the full number to verify.
Series features:
- Configure, trim and diagnose HART smart devices
- 5.7-inch color touchscreen, quad-core, 64 GB storage
- Bluetooth wireless, HART over Bluetooth
- Rechargeable Li-ion, 8+ hour battery
- Intrinsic safety Ex ia IIC T4, IP54
Related products in series: AMS Trex (FF version); AMS Device Manager software; 475 upgrade replacement
Matching products: Charger cradle, connection cable, protective boot, shoulder strap

6. Why Choose Us

Exact model match: We verify TREX2CHPNAWS1S as HART, Li-ion, Bluetooth wireless.
Authorized channel supply: Emerson AMS field communicators through regular channels.
Selection support: We help confirm HART/FF protocol, certification and support level.
Delivery & after-sales: Quotation, lead-time confirmation and order follow-up provided; for questions, please email us.

7. FAQ

Q1: What is TREX2CHPNAWS1S?

A: The Emerson AMS Trex handheld HART device communicator, rechargeable Li-ion, with Bluetooth wireless.

Q2: What protocol?

A: HART (this config); a FOUNDATION Fieldbus version also exists.

Q3: What can it do?

A: Configure, trim, diagnose and maintain smart transmitters, valve positioners and other HART devices.

Q4: What is Bluetooth for?

A: The redesigned AMS Trex supports HART over Bluetooth for wireless field connection and an expanded app library.

Q5: Hazardous-area rating?

A: Intrinsically safe ATEX/IECEx/CSA Ex ia IIC T4, IP54, for field use in hazardous areas.

Q6: Battery life?

A: Rechargeable Li-ion, 8+ hours typical. For the FF version or other configs, please email us.
